3" Top Discharge Butterfly Valve
Our Top Discharge Valves can be retrofitted into most existing top discharge arrangements on tanks up to 26,000 litres without the need for a recessed weld pad. The connection flange holes are slotted to allow connection to most known bolting pattern for common and uncommon tank weld pads.
The valve can be hermetically sealed and locked with a padlock or tamper evident seals to protect precious cargoes from unauthorized access. All flange mating surfaces are machined with serrations to comply with ASME B16.5 standards.
Replacement parts are interchangeable with most other major brands.
The valve is made entirely of 316 stainless steel with both PTFE and fluoroelastomer low temperature seals to guarantee the highest in chemical compatibility and reliability even in the harshest operating conditions.
3" Top Discharge Butterfly Valve
Features & Benefits
- Designed to mount on top of container
- Top discharge assembly
- Integrally cast TIR locking tags for adding tamper evident seals
- All contact parts are 316 stainless steel with PTFE and perfluoroelastomeric sealss
- Dual drilling to accept all available bolt patterns
Production Specifications
| Design Pressure | 6 BAR (87 PSI) |
| Test Pressure | 9 BAR (130 PSI) |
| Weight | 7.2 kg (16 lbs) |
